Product Overview :
A single cone spiral belt vacuum dryer is a type of drying machine that uses a spiral belt to rotate and lift materials, and simultaneously introduces heat transfer media (such as hot water, thermal oil, steam, etc.) into the conical jacket and hollow spiral belt. The heated materials are lifted from all sides and dropped from the middle, rapidly and continuously circulating and flipping, and the water vapor is promptly taken away by vacuuming the cylinder, achieving the purpose of drying and mixing the materials in a short period of time.
Summary:
A single cone spiral belt vacuum dryer is a type of drying machine that uses a spiral belt to rotate and lift materials, and simultaneously introduces heat transfer media (such as hot water, thermal oil, steam, etc.) into the conical jacket and hollow spiral belt. The heated materials are lifted from all sides and dropped from the middle, rapidly and continuously circulating and flipping, and the water vapor is promptly taken away by vacuuming the cylinder, achieving the purpose of drying and mixing the materials in a short period of time. Compared with traditional vertical mixers, there is no transmission mechanism inside the cylinder, which fundamentally eliminates material pollution caused by lubricating oil leakage. The operation is reliable and stable, especially suitable for powder and particle mixing with high hygiene requirements; It is also suitable for stirring and mixing viscous fluids or viscous or wet main materials; Compared with other horizontal dryers, it has the advantages of convenient discharge, 100% complete discharge, and easy operation and maintenance. Its drying efficiency is 3-5 times that of the same specification "double cone rotary vacuum dryer".
Characteristic:
1. The machine is directly driven by a reducer to rotate the agitator.
2. Widely applicable, it can be used for mixing powders with powders, powders with liquids, as well as for reaction equipment and drying equipment.
3. Spray devices can be added according to user requirements to spray an appropriate amount of liquid into the material.
4. The speed can be adjusted according to the process requirements, and when the speed is low, its drying effect dominates; When the speed is high. The mixed effect dominates, so by selecting this device, the original two devices needed to achieve the goal can now be combined into one, saving costs.
Technical parameters of single cone spiral belt vacuum dryer:
Single cone spiral belt vacuum dryer is a powder drying equipment used in industries such as pharmaceuticals, chemicals, pesticides, and food production for mixed drying machines. This machine completely changes the shortcomings of traditional drying equipment, such as large volume, high energy consumption, long working hours, low efficiency, high noise, easy agglomeration, multiple leakage points, and inconvenient cleaning and maintenance.
