Product Overview :
ZGH vertical high-speed mixer is a high-speed and efficient mixing equipment specially developed for powder material mixing, which solves the process problem of uniformly mixing various powder raw materials with water into wet materials in the food, pharmaceutical and other industries for many years. Previously, most manufacturers used mixing equipment such as trough mixers, V-shaped mixers, two-dimensional mixers, and three-dimensional mixers. However, they all had common problems such as long mixing time, uneven mixing, and a large number of small clusters and pieces. The products produced had color differences, flavors, and ingredients
Purpose:
● ZGH vertical high-speed mixer is specially designed for powder or low humidity materials, with efficient, uniform, and no dead corners in mixing;
● The material contact parts of this machine are made of stainless steel, and the mixing shaft is equipped with a sealing device, which can effectively prevent material mixing and ensure the service life of bearings and various transmission components.
Equipment features:
ZGH vertical high-speed mixer is a newly developed high-efficiency mixer by our company, which integrates advanced technologies from home and abroad. Its main features are as follows:
● Utilize the centrifugal force generated by the vertical high-speed rotating blade installed at the bottom of the machine body and apply it to the material, forming a vortex shape with the outer periphery rolling upwards and the center concave downwards, to fully mix the inner and outer rings, upper and lower layers of the material;
● Using the high-speed crushing blade installed on the side wall of the machine, the material rolling up from the outer ring is crushed, while also acting as a disturbance, increasing the relative motion between the materials and improving the mixing effect;
● Due to the combined effect of the two types of blades mentioned above, the material can be fully and uniformly mixed in a relatively short period of time, and its efficiency is unmatched by other types of mixers in China;
● The mixing bin has no dead corners, allows for quick feeding, and is easy to clean;
● The material contact parts of the machine are made of stainless steel, and there will be no material volatilization, deterioration, or loss during the mixing process, ensuring the process ratio requirements;
● This machine is suitable for mixing dry and wet materials of different proportions, especially for mixing and stirring various complex materials such as chicken essence, pharmaceutical granules, beverage granules, etc.
